This OpenGL tutorial is all about adding normals to your terrain to give the terrain a self shadowing system. You will notice with the previous one, if you add lighting and auto_normals, it will get darker the further away from the light the terrain is, but it wont differentiate between which faces are facing the light and which arent. This is all about adding specific normals to those faces to shadow your terrain.
This tutorial is going to extend on the last heightmap tutorial
The difference here is that I am now adding lighting to the
terrain using a thing known as a normal. I have also added a little scale
feature to the terrain, so you can set the spacing between the vertices.
So lets get started shall we
--------------------------------------------------
First Section: Variables
Now there are a few variables that I have added, some of them
are explained in the lighting tutorials.
This is the scale for the terrain, we can set
the distance between the vertices with this. This can
be used to create larger terrains.
float scale = 1;
here i am creating a struct for our normals
typedef struct
{
float x; the x position of the current normal
float y; the y position of the current normal
float z; the z position of the current normal
}NORMALS; I have chosen to call them NORMALS - can be whatever you want
NORMALS ab; normal for length AB - can be whatever you want
NORMALS ac; normal for length AC - can be whatever you want
NORMALS n; our final/main normal
here we set the materials for the terrain
GLfloat whiteDiffuseMaterial[] = {1.0, 1.0, 1.0}; set the diffuse material to white
GLfloat greyAmbientMaterial[] = {0.25, 0.25, 0.25}; set the shadows
material to grey, the lower the number, the more intense the shadows
GLfloat whiteSpecularMaterial[] = {1.0, 1.0, 1.0}; set the specular material to white
diffuse light color variables - 1,1,1 makes white
GLfloat dlr = 1.0;
GLfloat dlg = 1.0;
GLfloat dlb = 1.0;
ambient light color variables - 1,1,1 makes white
GLfloat alr = 1.0;
GLfloat alg = 1.0;
GLfloat alb = 1.0;
ligth position variables
GLfloat lx = -40.0; the x position
GLfloat ly = 100.0; the y position
GLfloat lz = -30.0; the z position
GLfloat lw = 0.0; setting this to 0 sets the light as a diffuse light
--------------------------------------------------
Section 2: Calculating the normals
here is our function to calculate the normals
with this you supply:
x1,y1,z1 - the points of the current vertex
x2,y2,z2 - the points of the vertex to the right
x3,y3,z3 - the points of the vertex to the left
each within the current shape.
void calculateNormals (float x1, float y1, float z1, float x2, float y2, float z2, float x3, float y3, float z3) {
double d; d will hold the distance of each vector normal
get the length of the vector to the right
ab.x = x2 - x1;
ab.y = y2 - y1;
ab.z = z2 - z1;
get the length of the vector to the left
ac.x = x3 - x1;
ac.y = y3 - y1;
ac.z = z3 - z1;
here we do our dot product
this is something you learn about when going
over vectors. a dot product is equal to 0, and
is therefore perpendicular to the current vector.
n.x = (ab.y * ac.z) - (ab.z * ac.y);
n.y = (ab.z * ac.x) - (ab.x * ac.z);
n.z = (ab.x * ac.y) - (ab.y * ac.x);
here we get the distance of our normal vector
d = sqrt((n.x*n.x) + (n.y*n.y) + (n.z*n.z));
then we normalize it by dividing the current
vector by its distance.
n.x = n.x / d;
n.y = n.y / d;
n.z = n.z / d;
}
--------------------------------------------------
Section 3: Displaying the Heightmap with the Normals
To do this the first thing we have to do is add materials
to the object as we are using lighting now and our
color function doesn't manage lights.
Now in here you will notice tha I call calculate
normals for each vertex and then add a normal.
The hardest part here is working our which
number goes with which x,y and z. But once
you work it out, I believe the results
are pretty good. Not the best but
alot better then without shading.
void DisplayHeightMap (void) {
float Height;
set the materials for the heightmap
glMaterialfv (GL_FRONT_AND_BACK, GL_DIFFUSE, whiteDiffuseMaterial);
glMaterialfv (GL_FRONT_AND_BACK, GL_AMBIENT,greyAmbientMaterial);
glMaterialfv (GL_FRONT_AND_BACK, GL_SPECULAR, whiteSpecularMaterial);
for (mapX = 1; mapX < MapWidth; mapX +=4){
for (mapZ = 1; mapZ < MapHeight; mapZ+=4){
float Height1 = HeightMap[mapX][mapZ];
float Height2 = HeightMap[mapX][mapZ+4];
float Height3 = HeightMap[mapX+4][mapZ];
float Height4 = HeightMap[mapX+4][mapZ+4];
glBegin(GL_TRIANGLE_STRIP);
Height = HeightMap[mapX][mapZ];
glTexCoord2f(0,0);
now we calculate our normals, we do this for each vertex
calculateNormals(mapX,Height1,mapZ,mapX+4,Height3,mapZ,mapX,Height2,mapZ+4);
then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f(mapX*scale,Height,mapZ*scale);
Height = HeightMap[mapX][mapZ+4];
glTexCoord2f(0,1);
now we calculate our normals, we do this for each vertex
calculateNormals(mapX,Height2,mapZ+4,mapX,Height1,mapZ,mapX+4,Height4,mapZ+4);
then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f(mapX*scale,Height,(mapZ+4)*scale);
Height = HeightMap[mapX+4][mapZ];
glTexCoord2f(1,0);
now we calculate our normals, we do this for each vertex
calculateNormals(mapX+4,Height3,mapZ,mapX+4,Height4,mapZ+4,mapX,Height1,mapZ);
then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f((mapX+4)*scale,Height,mapZ*scale);
Height = HeightMap[mapX+4][mapZ+4];
glTexCoord2f(1,1);
now we calculate our normals, we do this for each vertex
calculateNormals(mapX+4,Height4,mapZ+4,mapX,Height2,mapZ+4,mapX+4,Height3,mapZ);
then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f((mapX+4)*scale,Height,(mapZ+4)*scale);
glEnd();
}
}
}
And if you can work that all out, you should have a little idea on how
to use normals. if you are not sure of the math behind it. I will
be writing a tutorial on vector math in the forum, or you
can just google search it as normals are not just for opengl
they are for all 3D programs.
#include <GL/gl.h>
#include <GL/glut.h>
#include <windows.h>
#include <stdio.h>
#include <math.h>
#include <iostream.h>
int mapX;
int mapY;
int mapZ;
const MapWidth = 384;
const MapHeight = 384;
float scale = 1; //the scale for the terrain *also new*
//here i am creating a struct for our normals
typedef struct
{
float x; //the x position of the current normal
float y; //the y position of the current normal
float z; //the z position of the current normal
}NORMALS; //I have chosen to call them NORMALS - can be whatever you want
NORMALS ab; //normal for length AB - can be whatever you want
NORMALS ac; //normal for length AC - can be whatever you want
NORMALS n; //our final/main normal
//here we set the materials for the terrain
GLfloat whiteDiffuseMaterial[] = {1.0, 1.0, 1.0}; //set the diffuse to white
GLfloat greyAmbientMaterial[] = {0.25, 0.25, 0.25}; //set the shadows
to grey, the lower the number, the more intense the shadows
GLfloat whiteSpecularMaterial[] = {1.0, 1.0, 1.0}; //set the specular to white
//diffuse light color variables
GLfloat dlr = 1.0;
GLfloat dlg = 1.0;
GLfloat dlb = 1.0;
//ambient light color variables
GLfloat alr = 1.0;
GLfloat alg = 1.0;
GLfloat alb = 1.0;
//ligth position variables
GLfloat lx = -50.0;
GLfloat ly = 100.0;
GLfloat lz = -50.0;
GLfloat lw = 0.0; //setting this to 0 sets the light as a diffuse light
GLuint texture[10];
BYTE HeightMap[MapWidth][MapHeight];
GLuint LoadTexture( const char * filename, int width, int height ){
GLuint texture;
unsigned char * data;
FILE * file;
//The following code will read in our RAW file
file = fopen( filename, "rb" );
if ( file == NULL ) return 0;
data = (unsigned char *)malloc( width * height * 3 );
fread( data, width * height * 3, 1, file );
fclose( file );
glGenTextures( 1, &texture ); //generate the texture with the loaded data
glBindTexture( GL_TEXTURE_2D, texture ); //bind the texture to it's array
glTexEnvf( GL_TEXTURE_ENV, GL_TEXTURE_ENV_MODE, GL_MODULATE ); //set texture environment parameters
//here we are setting what textures to use and when. The MIN filter is which quality to show
//when the texture is near the view, and the MAG filter is which quality to show when the texture
//is far from the view.
//The qualities are (in order from worst to best)
//GL_NEAREST
//GL_LINEAR
//GL_LINEAR_MIPMAP_NEAREST
//GL_LINEAR_MIPMAP_LINEAR
//And if you go and use extensions, you can use Anisotropic filtering textures which are of an
//even better quality, but this will do for now.
glTexParameterf( GL_TEXTURE_2D, GL_TEXTURE_MIN_FILTER, GL_LINEAR_MIPMAP_LINEAR );
glTexParameterf( GL_TEXTURE_2D, GL_TEXTURE_MAG_FILTER, GL_LINEAR_MIPMAP_LINEAR );
//Here we are setting the parameter to repeat the texture instead of clamping the texture
//to the edge of our shape.
glTexParameterf( GL_TEXTURE_2D, GL_TEXTURE_WRAP_S, GL_REPEAT );
glTexParameterf( GL_TEXTURE_2D, GL_TEXTURE_WRAP_T, GL_REPEAT );
//Generate the texture with mipmaps
gluBuild2DMipmaps( GL_TEXTURE_2D, 3, width, height, GL_RGB, GL_UNSIGNED_BYTE, data );
free( data ); //free the texture
return texture; //return whether it was successfull
}
void FreeTexture( GLuint texture )
{
glDeleteTextures( 1, &texture );
}
void LoadHeightMap (char* Filename, int Width, int Height) {
int smoothen;
FILE * File;
File = fopen( Filename, "rb" );
fread( HeightMap, 1, Width * Height * 3, File );
fclose( File );
for (smoothen = 0; smoothen < 3; smoothen++){
for (mapX = 1; mapX < Width; mapX ++){
for (mapZ = 1; mapZ < Height * 3; mapZ++){
mapY = HeightMap[mapX][mapZ];
mapY += HeightMap[mapX-1][mapZ];
mapY += HeightMap[mapX+1][mapZ];
mapY += HeightMap[mapX][mapZ-1];
mapY += HeightMap[mapX][mapZ+1];
mapY += HeightMap[mapX-1][mapZ-1];
mapY += HeightMap[mapX-1][mapZ+1];
mapY += HeightMap[mapX+1][mapZ-1];
mapY += HeightMap[mapX+1][mapZ+1];
mapY = mapY/9;
HeightMap[mapX][mapZ] = mapY ;
}
}
}
}
//here is our function to calculate the normals
//with this you supply:
//x1,y1,z1 - the points of the current vertex
//x2,y2,z2 - the points of the vertex to the right
//x3,y3,z3 - the points of the vertex to the left
//each within the current shape.
void calculateNormals (float x1, float y1, float z1, float x2, float y2, float z2, float x3, float y3, float z3) {
double d; //d will hold the distance of each vector normal
//get the length of the vector to the right
ab.x = x2 - x1;
ab.y = y2 - y1;
ab.z = z2 - z1;
//get the length of the vector to the left
ac.x = x3 - x1;
ac.y = y3 - y1;
ac.z = z3 - z1;
//here we do our dot product
//this is something you learn about when going
//over vectors. a dot product is equal to 0, and
//is therefore perpendicular to the current vector.
n.x = (ab.y * ac.z) - (ab.z * ac.y);
n.y = (ab.z * ac.x) - (ab.x * ac.z);
n.z = (ab.x * ac.y) - (ab.y * ac.x);
//here we get the distance of our normal vector
d = sqrt((n.x*n.x) + (n.y*n.y) + (n.z*n.z));
//then we normalize it by dividing the current
//vector by its distance.
n.x = n.x / d;
n.y = n.y / d;
n.z = n.z / d;
}
void DisplayHeightMap (void) {
float Height;
//set the materials for the heightmap
glMaterialfv (GL_FRONT_AND_BACK, GL_DIFFUSE, whiteDiffuseMaterial);
glMaterialfv (GL_FRONT_AND_BACK, GL_AMBIENT,greyAmbientMaterial);
glMaterialfv (GL_FRONT_AND_BACK, GL_SPECULAR, whiteSpecularMaterial);
for (mapX = 1; mapX < MapWidth; mapX +=4){
for (mapZ = 1; mapZ < MapHeight; mapZ+=4){
float Height1 = HeightMap[mapX][mapZ];
float Height2 = HeightMap[mapX][mapZ+4];
float Height3 = HeightMap[mapX+4][mapZ];
float Height4 = HeightMap[mapX+4][mapZ+4];
glBegin(GL_TRIANGLE_STRIP);
Height = HeightMap[mapX][mapZ];
glTexCoord2f(0,0);
//now we calculate our normals, we do this for each vertex
calculateNormals(mapX,Height1,mapZ,mapX+4,Height3,mapZ,mapX,Height2,mapZ+4);
//then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f(mapX*scale,Height,mapZ*scale);
Height = HeightMap[mapX][mapZ+4];
glTexCoord2f(0,1);
//now we calculate our normals, we do this for each vertex
calculateNormals(mapX,Height2,mapZ+4,mapX,Height1,mapZ,mapX+4,Height4,mapZ+4);
//then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f(mapX*scale,Height,(mapZ+4)*scale);
Height = HeightMap[mapX+4][mapZ];
glTexCoord2f(1,0);
//now we calculate our normals, we do this for each vertex
calculateNormals(mapX+4,Height3,mapZ,mapX+4,Height4,mapZ+4,mapX,Height1,mapZ);
//then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f((mapX+4)*scale,Height,mapZ*scale);
Height = HeightMap[mapX+4][mapZ+4];
glTexCoord2f(1,1);
//now we calculate our normals, we do this for each vertex
calculateNormals(mapX+4,Height4,mapZ+4,mapX,Height2,mapZ+4,mapX+4,Height3,mapZ);
//then we add the normal
glNormal3f(n.x,n.y,n.z);
glVertex3f((mapX+4)*scale,Height,(mapZ+4)*scale);
glEnd();
}
}
}
void enable (void) {
glEnable(GL_DEPTH_TEST); //enable the depth testing
glDepthFunc(GL_LEQUAL); //set the depth function
glFrontFace(GL_CCW); //set which face is facing forward
glCullFace(GL_BACK); //set the face to be culled
glEnable(GL_CULL_FACE); //enable culling to speed up the processing time
glShadeModel (GL_SMOOTH); //set the shade model to smooth
glEnable(GL_TEXTURE_2D); //enable texturing
glEnable(GL_LIGHTING); //enable the lighting
glEnable(GL_LIGHT0); //enable our diffuse light
glEnable (GL_LIGHT1); //enable our ambient light
glEnable(GL_NORMALIZE); //enable normalizing of normals, wont make a difference if disabled
}
void lights (void) {
GLfloat DiffuseLight[] = {dlr, dlg, dlb}; //set DiffuseLight[] to the specified values
GLfloat AmbientLight[] = {alr, alg, alb}; //set AmbientLight[] to the specified values
glLightfv (GL_LIGHT0, GL_DIFFUSE, DiffuseLight); //change the light accordingly
glLightfv (GL_LIGHT1, GL_AMBIENT, AmbientLight); //change the light accordingly
GLfloat LightPosition[] = {lx, ly, lz, lw}; //set the LightPosition to the specified values
glLightfv (GL_LIGHT0, GL_POSITION, LightPosition); //change the light accordingly
}
void display (void) {
glClearColor (0.0,0.0,0.0,1.0);
glClear (GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
glLoadIdentity();
enable();
lights(); //setup the lights
glTranslatef(-50, -100, -50); //move to a position so we can see our terrain when rotated
glRotatef(30, 1,0,0); //rotate to look down on the terrain
glRotatef(150, 0,1,0); //rotate to put the terrain into view
glBindTexture(GL_TEXTURE_2D, texture[0]); //bind our texture
DisplayHeightMap(); //display our heightmap
glutSwapBuffers();
}
void init (void) {
texture[0] = LoadTexture("texture.raw", 256, 256);
LoadHeightMap ("height.raw", 128, 128);
}
void reshape (int w, int h) {
glViewport (0, 0, (GLsizei)w, (GLsizei)h);
glMatrixMode (GL_PROJECTION);
glLoadIdentity ();
gluPerspective (60, (GLfloat)w / (GLfloat)h, 0.01, 500.0);
glMatrixMode (GL_MODELVIEW);
}
int main (int argc, char **argv) {
glutInit (&argc, argv);
glutInitDisplayMode (GLUT_DOUBLE | GLUT_DEPTH | GLUT_RGBA);
glutInitWindowSize (500, 500);
glutInitWindowPosition (100, 100);
glutCreateWindow ("A basic OpenGL Window");
init();
glutDisplayFunc (display);
glutIdleFunc (display);
glutReshapeFunc (reshape);
glutMainLoop ();
return 0;
}
Download C++ Source Code for this Tutorial
Download Visual Basic Source Code for this Tutorial (soon)
